Human Machine Interface Touch Screen size 10.4 inch GT2510-VTWD Mitsubishi Electric

Markenbezeichnung:	Mitsubishi
Modellnummer:	Fahrzeuge, für die die Genehmigung erteilt wurde
MOQ:	1
Preis:	Verhandlungsfähig
Zahlungsbedingungen:	Akkreditiv, Dokumenteninkasso, Dokument gegen Zahlung, Überweisung, Western Union, MoneyGram
Versorgungsfähigkeit:	Vorräte

Einzelheiten

Herkunftsort:

Japan

Zertifizierung:

Verpackung Informationen:

Neue Originalbox

Versorgungsmaterial-Fähigkeit:

Vorräte

Beschreibung des Produkts

Detailed Product Description

Brand:	Mitsubishi	Model Item:	GT2510-VTWD
Plan Of Original:	Japan	Screen Size:	10.4"
Internal Memory:	38MB	Resolution:	800 X 600pixels
Supply Voltage:	100-240VAC	Power Supply:	24 V Dc
Keyboard::	Touch Screen
Highlight:	hmi display touch screen , industrial hmi panels

Human Machine Interface Touch Screen size 10.4 inch GT2510-VTWD Mitsubishi Electric

Detailed Product Description

◆ Display device: TFT color LCD screen

◆ Screen size: 10.4 inches

◆ GT2510-VTWD resolution: VGA: 640*480 points

◆ Display size: 211.2 (8.315) (W) * 158.4 (6.236) (H) mm (inch)

◆ Display the number of characters:

·16 dot matrix standard font: 40 words * 30 lines (full angle)

·12 dot matrix standard font: 53 words * 40 lines (full angle)

◆ Display color: 65536 colors

◆ Brightness adjustment: 32 levels

◆ Maximum number of screens that can be registered: 4096 screens

◆ Background light: LED (cannot be replaced)

◆ Background lamp life: about 60,000 hours (using the ambient temperature of 25 ° C, the time when the brightness is 50%)

【touch screen】

◆ Mode: Analog resistance film method

◆ Key size: minimum 2*2 points (per key)

◆ Press the number of points at the same time: Can not press simultaneously

◆ Life: more than 1 million times (operating force of 0.98N or less)

Product Details

Specifications

Screen size:	10.4"
Display type:	TFT, LCD colour
Display dimensions:	w211.2 x h158.4mm
Graphical resolution:	640 x 480 pixels
Power supply:	24V d.c.
Interface:	RS422/485, RS232, Ethernet (TCP/IP), USB (rear) and SD card
Overall dimensions:	w303 x h218 x d52mm

Features:

Quick Detail

GT25 model

Model		Screen size	Display section Display color	Panel color	Power	Remarks
GT2512	GT2512-STBA	12.1" SVGA	TFT color 65536 colors	Black	100 to 240 V AC	-
	GT2512-STBD			Black	24 V DC	-
	GT2512F-STNA			-	100 to 240 V AC	Open frame model
	GT2512F-STND			-	24 V DC	Open frame model
GT2510	GT2510-VTBA	10.4" VGA		Black	100 to 240 V AC	-
	GT2510-VTBD			Black	24 V DC
	GT2510-VTWA			White	100 to 240 V AC
	GT2510-VTWD			White	24 V DC
	GT2510F-VTNA			-	100 to 240 V AC	Open frame model
	GT2510F-VTND			-	24 V DC	Open frame model
GT2508	GT2508-VTBA	8.4" VGA		Black	100 to 240 V AC	-
	GT2508-VTBD			Black	24 V DC
	GT2508-VTWA			White	100 to 240 V AC
	GT2508-VTWD			White	24 V DC
	GT2508F-VTNA			-	100 to 240 V AC	Open frame model
	GT2508F-VTND			-	24 V DC	Open frame model
GT2505	GT2505-VTBD	5.7" VGA		Black	24 V DC	-
