Einzelheiten zu den Produkten

Zu Hause Produits

AB 1747-KFC15 ， SLC 500 ControlNet RS-232 Interface Module

Name: AB 1747-KFC15 ， SLC 500 ControlNet RS-232 Interface Module
Brand: Hontai Machinery and equipment (HK) Co. ltd
SKU: 1747-KFC15
Price: 210.00 USD
Availability: InStock

Markenbezeichnung:	AB
Modellnummer:	1747-KFC15
MOQ:	1
Preis:	Negotiations

Einzelheiten

Beschreibung des Produkts

Einzelheiten

Herkunftsort:

USA

Modultyp:

ControlNet-RS 232-Schnittstelle-Modul

Kommunikation:

Hafen RS-232

Rückwand-Strom (5 Volt):

150 Milli-Amperes

Rückwand-Strom (24 Volt):

40 Milli-Amperes

Anschlüsse:

6-Pin Phoenix Verbindungsstück

Verpackung Informationen:

Neue Originalbox

Beschreibung des Produkts

AB 1747-KFC15 , SLC 500 ControlNet RS-232 Interface Module

Technical Specifications for 1747-KFC15

Manufacturer	Rockwell Automation
Brand	AB
Part Number/Catalog No.	1747-KFC15
Series	SLC 500
Module Type	ControlNet RS-232 Interface Module
Communication	RS-232 Port
Backplane Current (5 Volts)	640 milliamps

Backplane Current (5 Volts)	150 milliamps
Backplane Current (24 Volts)	40 milliamps
Cable	Belden 9463
Connectors	6-Pin Phoenix Connector
Weight	0.37 pounds (168 grams)
Dimensions	5.72 x 1.37 x 5.15 inches
Operating Temperature	0-60 Celsius

About 1747-KFC15

The AB 1747-KFC15 is an SLC500 ControlNet RS-232 Interface module. This module communicates with the SLC 500 processor using the ControlNet network. The AB 1747-KFC15 examines the processor’s ladder program. This module comes with program operation monitoring and program-changing software. This module is a bridge between the ControlNet network and the SLC500 processor’s RS-232C serial port. The 1747-KFC15 connects to a ControlNet network of one (channel A) or both of its BNC connectors. It connects via standard ControlNet coaxial tap. The AB 1747-KFC15 has two connection ports. There are RS-232C serial port and network access port. The RS-232C serial port provides half duplex and full duplex compatibility. Both communicate with the serial port on your SLC500 processor. The network access port connects the ControlNet programming terminal to this module. This is for full network access without interrupting the cable wiring. The serial port uses the DF1 protocol when the network access port is handled directly.
The AB 1747-KFC15 is configurable with the DIP and rotary buttons in the module. This module is open equipment. It must be installed in its enclosure during operation for providing safety protection. This module has an operating temperature of 32-140° F. The storage temperature of this module is from –40-185° F. The relative humidity of this module is from 5-95% non condensing. Do not disconnect the connectors unless the power has been switched off.

Description: The AB 1747-KFC15 is a SLC 500 ControlNet RS-232 Interface Module. This ControlNet RS-232 Interface Module has RS-232 Port Communication along with 640 milliamps Backplane Current (5 Volts).
