Yaskawa SGDV-R70A21A Servo Motor AZ Sigmas 200 Volt 50W ML3 Rot Sensor Amplifier

Yaskawa SGDV-R70A21A Servo Motor AZ Sigmas 200 Volt 50W ML3 Rot Sensor Amplifier

Markenbezeichnung: Yaskawa
Modellnummer: Die in Absatz 1 Buchstabe b genannten Vorschriften gelten nicht für Fahrzeuge, die mit einem Fahrzeu
MOQ: 1
Preis: Negotiations
Einzelheiten
Herkunftsort:
Japan
Stromspannung:
220V
Leistung:
0,05 kW
Verpackung Informationen:
Neue Originalbox
Hervorheben:

Yaskawa servo motor 200V

,

AZ Sigmas servo amplifier

,

servo motor with ML3 sensor

Beschreibung des Produkts
Yaskawa SGDV-R70A21A Servo Motor AZ Sigmas 200 Volt 50W ML3 Rot Sensor Amplifier
Yaskawa SGDV-R70A21A Servo Sigma 5 series maximizes the machine's potential and performance with high-speed positioning, with the highest precision, voltage/pulse analog input, or MECHATROLINK- communication II, III, operate with high working frequency up to 1.6kHz.
Technical Specifications
Model SGDV-R70A21A
Power 0.05kW
Power supply 220V
Operating temperature 0 to 55°C
Storage temperature -20 to 85°C
Operating humidity Lower than 90%
Maximum encoder resolution Up to 20-bit
Maximum frequency 1.6kHz
Sigma 5 Series Features
  • Power range from 0.05 to 15kw
  • Real-time communication MECHATROLINK-II and III
  • Save with control, and respond faster
  • Error diagnosis and warning function
  • Wide range of motors to suit any machine building requirements
  • High precision motion control
  • Higher bandwidth response (loop frequency response up to 1.6kHz)
  • Smooth control at low engine rpm, thanks to higher encoder resolution
  • New upgrades eliminate vibrations and optimize machine performance
  • Install faster
  • Operates smoothly at high speeds, with minimal vibration
  • Communication interface: (Devicenet, Profibus, etc.)
  • Fully closed-loop feedback
  • Protection functions: Overcurrent, overload, main circuit voltage error, heatsink overheating, phase loss, overspeed, encoder error, encoder connection loss, CPU error, parameter error
Compatible 220V Servo Motor Lines
SGMMV, SGMJV, SGMAV, SGMGV, SGMSV
