AJ65DBTB1-32T1 Mitsubishi Universal Model Redundant Power Supply Module

Name: AJ65DBTB1-32T1 Mitsubishi Universal Model Redundant Power Supply Module
Brand: Hontai Machinery and equipment (HK) Co. ltd
SKU: AJ65DBTB1-32T1
Price: 210.00 USD
Availability: InStock

Markenbezeichnung:	MITSUBISHI
Modellnummer:	AJ65DBTB1-32T1
MOQ:	1
Preis:	Negotiations

Einzelheiten

Beschreibung des Produkts

Einzelheiten

Herkunftsort:

Japan

Programmkapazität:

8 K Schritte

Verarbeitungsgeschwindigkeit der grundlegenden Operation (LD-Anweisung):

0,12 μs

Eingang:

24VDC

Ausgabe:

12/24VDC (0,5a).

Verpackung Informationen:

Neue Originalbox

Hervorheben:

Mitsubishi redundant power supply module

universal power supply module 32T1

electronic control relay power module

Beschreibung des Produkts

AJ65DBTB1-32T1 Mitsubishi Universal Model Redundant Power Supply Module

The Mitsubishi AJ65DBTB1-32T is a high-speed, 32-channel analog voltage input module designed for the MELSEC-Q series of Programmable Logic Controllers (PLCs). This module acts as a critical interface, converting real-world analog signals from sensors (such as temperature, pressure, or speed sensors) into precise digital values that the PLC CPU can process. It is engineered for industrial automation applications requiring the monitoring of multiple points with high density and accuracy.

Key Specifications

Number of Outputs	32	Representative Standard	UL
Leakage current when OFF	0.1 mA or less	Output answer time	1.5ms
Terminal shape	Screw / 2-piece terminal block dust-proof type	Maximum Switching Voltage	DC12/24V
Protective Function	NA	Type of unit	Transistor output (sink)
External connection	1-wire type	I/O unit power supply current	65 mA or less
Rated load current	0.5A

Product Features

High Channel Density: Integrates 32 analog input channels into a single module
High-Speed Conversion: Fast conversion speed for rapid data acquisition
Direct Connection to Sensors: Supports voltage input ranges for various analog sensors
High Resolution: 16-bit digital resolution (15 bits plus sign) for precise measurement
Dedicated Utility Software: Simplified configuration with GX Configurator-AD software
Digital Offset/Gain Adjustment: Software calibration enhances long-term stability
Intelligent Function Module: Recognized as an intelligent module by QCPU

Technical Specifications

Product Series	MELSEC-Q Series
Module Type	Analog Input
Number of Channels	32 channels
Input Type	DC Voltage
Input Ranges	0 to 10V DC, ±10V DC (user-selectable)
Digital Output	16-bit binary (15 bits + sign for ±10V range)
Resolution	1/32000 (for 0-10V), 1/64000 (for ±10V, effective)
Accuracy	±0.1% of full scale (at 25°C)
Conversion Speed	80 µs/channel (2.56 ms for all 32 ch)
Isolation	Photocoupler isolation between I/O terminals and PLC
External Wiring	40-pin connector (requires separate connector block)
Power Supply	5V DC (from main base unit) / 70 mA
Compatible PLC	MELSEC-QnA, Q Series (requires AnS/A series extension base)

Model Variants

Model: AJ65DBTB1-32D
Input 32 points: 24VDC (positive/negative common shared).
MITSUBISHI Transistor Output Module 1-wire type.
Terminal block type. Response time 10ms.
Screw/2-piece terminal block Dustproof MITSUBISHI Transistor Output Module type

Model: AJ65DBTB1-32R
Output MITSUBISHI Transistor Output Module 32 points: 24VDC/240VAC (2A).
MITSUBISHI AJ65DBTB1-32T1 Relay output. 1-wire type.
Terminal block type. Screw/2-piece terminal block Dustproof type

Model: AJ65DBTB1-32DT1
Input 16 points: 24VDC (positive common). Response time 10ms.
Output 16 points: 12/24VDC (0.5A). Transistor output (sink type).
1-wire type Terminal block type. Screw/2-piece terminal block Dustproof type

Additional Specifications

For Use With	MELSEC Q Series
Number of I/O	2048
Manufacturer Series	MELSEC Q
Input Type	Analogue, Digital
Voltage Category	5 V dc
Output Type	Analogue, Digital
Communication Port Type	RS232C
Program Capacity	32 kB
Programming Interface	Computer, Operating Panel
Dimensions	89.3 x 27.4 x 98 mm
Operating Temperature	0°C to +55°C
Mounting Type	DIN Rail
Memory	94 kB
Battery Backup	Yes

Q01CPU	Q02(H)CPU	Q06HCPU
Q12HCPU	Q25HCPU	Q02PHCPU
Q06PHCPU	Q12PHCPU	Q25PHCPU
Q00UCPU	Q01UCPU	Q02UCPU
Q03UDVCPU	Q03UD(E)CPU	Q04UDVCPU
